Manual Smart Card Sheet Collator and Bonder RFID Card Inlay Prodution YLB-1
1. General Description of Manual Smart Card Sheet Collator and Bonder RFID Card Inlay Prodution YLB-1
Controlled by solid relay, the machine applies the imported temperature control system for temperature controlling, and time relay is used to control bonding time.
It can bond the materials as below:
PVC, ABS, PET, etc;
Note: different materials have different bonding parameters (like temperature, Time and Pressure)
2. Features of Manual Smart Card Sheet Collator and Bonder RFID Card Inlay Prodution YLB-1
Key Features:
1. The machine uses double cylinders for moving power, and the pressure is adjustable.
2. It is equipped with 3 bonding heads. The bonding position can be adjusted.
3. It applies electrical heater to heat up and uses the temperature controller to control the temperature.
4. Bonding time is controlled by time relay, and it is simple to set.
3. Technical Parameter of Manual Smart Card Sheet Collator and Bonder RFID Card Inlay Prodution YLB-1
Manual Smart Card Sheet Collator and Bonder RFID Card Inlay Prodution YLB-1 is also called Manual Sheet Collating and Bonding Machine/Manual Card Sheet Collator and Bonder YLB-1
(card sheet bonding machine, card sheet collating machine, INLAY sheet bonding machine, manual card sheet collating and bonding machine, card machine, smart card machine)
★ Main Technical Parameters
| Power Supply | AC 220V/50 HZ | Weld Spot Quantity | 2-3 (adjusted position) |
| Air Source | 6 kg/c㎡(Dry) | Weight | Approx 50Kg |
| Total Power | 2KW | Available Sheet | 3X8,4X8,5X5 |
| Temp Control Range | 0-400℃ | Operator | 1 person |
| Temp Control Precision | ±2℃ | Dimension | L600×W500×H800mm |
| Capacity | 800~1200 sheet/hour | | |
4. Packing of Manual Smart Card Sheet Collator and Bonder RFID Card Inlay Prodution YLB-1
Packing information: using the PE film as the protection fims insides, standard export plywood case outside;
Our service :
Pre-sale
(1) Professional suggestions (raw material matching, machine selection, the condition of building factory, feasibility analysis for brick machine production line)
(2) Device model choice (recommend the best machine according to the raw material, capacity and the size of brick)
(3) Efficient on-line service
(4) Welcome to visit our factory and production line any time, if you need, we can make invitation letter for you.
(5) Introduce the company file, product categories and production process.
Sale:
(1) Update the production scheduling in time
(2) Quality supervision
(3) Product acceptance
(4) Shipping on time
After-sale:
(1) The engineer will guide to carry out the plant at the clients side if needed.
(2) Set up, fix, and operate
(3) offer training to the operator until they are satisfied at clients side.
(4) Skill support the whole using life.
(5) Recall clients regularly ,get feedback in time ,keep well communication with each other
Guarantee
(1)We can supply one year guarantee period for our card machines, if the client have any question ,they could contact our service department any time ,we will supply efficient service .
(2)Within one year ,if the client meet the unsolvable questions ,we can make site supporting.
